Corrugated strapping machine with 4-sided squaring station TP-702CQ

The TP-702CQ is based on the TP-702C high-speed corrugated strapping machine combined with the C1-BQ 4-sided squaring station. It incorporates all the innovative features of the TP-702C. The backstop, pusher and side squaring device ensure precise package control and integrity during the strapping cycle. Easy package size changeover eliminates downtime and makes production more efficient. A truly user-friendly machine for your case-making and flexo folder-gluer lines.

strapping machine with 4-sided squaring station TP-702CQ

TP-702CQ characteristics :

  • Corrugated strapping
  • 4-sided squaring station
  • Can be integrated into an automatic production line
  • Machine equipped with 4 wheels, 2 with brakes
  • Equipped with variable-speed conveyor for pack infeed
  • Full-width pneumatic press
  • Adjustable pressure on press and square
  • Electronic tension adjustment
  • Tension from 1 to 32 kg
  • Output = 17 strappings/minute (single strapping)
  • Output = 13 straps/minute (double strapping)
  • Strap widths: 5 – 6 – 9 mm
  • Automatic strap ejection
  • Multiple strapping function
  • Table height adjustable from 700 to 1000 mm
  • Adjustable speed from 15 to 60 m/min
  • LCD display with Siemens PLC and HMI for viewing and setting parameters
  • Max. package weight: 35 kg

Strap dispenser Jumbo 🔵⚪🔴

How many coil changes do you make per day or per week in your automatic strapping machine?

Jumbo is an economical solution…
